10
Match Output)
PB2
AIN0 (Analog Comparator Positive Input),
INT2 (External Interrupt 2 Input)
PB1
T1 (Timer/Counter1 External Counter Input)
PB0
T0 (Timer/Counter0 External Counter Input),
XCK (USART External Clock Input/Output)
c. Pin 22 sampai 29 (Port C) dapat digunakan sebagai,
Tabel 2.3 Tabel Fungsi Khusus Port C
PC7
TOSC2 (Timer Oscillator Pin 2)
PC6
TOSC1 (Timer Oscillator Pin 1)
PC5
TDI (JTAG Test Data In)
PC4
TDO (JTAG Test Data Out)
PC3
TMS (JTAG Test Mode Select)
PC2
TCK (JTAG Test Clock)
PC1
SDA (Two-wire Serial Bus Data
Input/Output Line)
PC0
SCL (Two-wire Serial Bus Clock Line)
d. Pin 14 sampai 21 (Port D) dapat digunakan sebagai,
Tabel 2.4 Tabel Fungsi Khusus Port D
OC2 (Timer/Counter2 Output Compare
PD7
Match Output)
 |
